Cryo dewars, shallow wide mouth

The Pope Low Form Shallow (open design - no lid) Dewars permit essential operations not practical with standard cylindrical or spherical dewars.These operations include:Rapid freezing and recovery of tissue/organ specimensInsertion of small flasks in dewarAgitation in dewar with magnetic stirrerTempering of stirring rods, pestles and other small objectsThe protective aluminium bases on both styles extend the full height of the Dewars. Note that protected vacuum tip-off tubulations are offset to the side to minimise space between the Dewar bottoms and magnetic stirrers. The hemispherical line has been expanded to provide additional Dewars to fit larger sizes.Economies in coolant use will be realised in all operations where Pope Low Form Shallow Dewars are more practical. Cooling range from dry ice/acetone to liquid nitrogen. Pope Low Form Shallow Dewars are available in several sizes and two configurations, hem...

The Pope Low Form Shallow (open design - no lid) Dewars permit essential operations not practical with standard cylindrical or spherical dewars.

These operations include:

  • Rapid freezing and recovery of tissue/organ specimens
  • Insertion of small flasks in dewar
  • Agitation in dewar with magnetic stirrer
  • Tempering of stirring rods, pestles and other small objects

The protective aluminium bases on both styles extend the full height of the Dewars. Note that protected vacuum tip-off tubulations are offset to the side to minimise space between the Dewar bottoms and magnetic stirrers. The hemispherical line has been expanded to provide additional Dewars to fit larger sizes.

Economies in coolant use will be realised in all operations where Pope Low Form Shallow Dewars are more practical. Cooling range from dry ice/acetone to liquid nitrogen. Pope Low Form Shallow Dewars are available in several sizes and two configurations, hemispherical and cylindrical (with semi-flat bottom). The cylindrical configuration increases coolant capacity.Holding time 2-6 hours depending on volume.

Code Description Type Inside diameter Inside Depth Outside diameter Height Volume
YTP81740-10
600ml
Full Base
Hemispherical 140mm 65mm 165mm 95mm 500ml
YTP81740-20
1000ml
Full Base
Hemispherical 160mm 88mm 186mm 119mm 1L
YTP81740-30
350ml
Full Base
Cylindrical 80mm 75mm 101mm 117mm 100ml
YTP81740-40
850ml
Full Base
Cylindrical 130mm 75mm 160mm 110mm 500ml


Code Title Style Volume Pack Size Availability Price Updated: 15-07-2024
YTP81740-10 Cryo dewars, shallow wide mouth Hemispherical 600ml Each 3 weeks $723.00 AUD
YTP81740-20 Cryo dewars, shallow wide mouth Hemispherical 1000ml Each 3 weeks $934.00 AUD
YTP81740-30 Cryo dewars, shallow wide mouth Cylindrical 350ml Each 3 weeks $680.00 AUD
YTP81740-40 Cryo dewars, shallow wide mouth Cylindrical 850ml Each 3 weeks $877.00 AUD
